Bike condition
All-mountain
-
Frame
Genius Carbon HMF Mainframe with Alloy 6061 Swingarm, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
-
Fork
FOX 36 Float Rhythm Air Grip3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 160mm travel
-
Rear shock
FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large air volume / DPS / Reb. Adj., Travel 150-100-Lockout / T185X55mm
-
Remote system
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes
-
Rear derailleur
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
-
Shifters
Shimano Deore SL-M6100-IR / Rapidfire Plus, Ispec EV clamp
-
Crankset
Shimano SLX FC-M7120-1, Hollowtech 2, 55mm CL / 30T
-
Chainguide
SCOTT custom
-
BB-Set
Shimano BB-MT500 / shell 41x92mm
-
Chain
Shimano Deore CN-M6100
-
Cassette
Shimano Deore CS-M6100-12 / 10-51 T
-
Brakes
Shimano Deore M6120 4 Piston Disc
-
Rotor
Shimano SM-RT64 CL / 203/F and 180/R
-
Handlebar
Syncros Hixon 1.5 Alloy 7050, Size S & M 15mm rise / Size L 25mm rise, back sweep 8° / 780mm, Syncros Endurance lock-on grips
-
H'stem
Syncros AM 1.5, Syncros Cable Integration System, 4° rise / 7050 Alloy / 31.8mm / 1 1/8"
-
Seatpost
Syncros Duncan Dropper Post 1.5, 31.6mm / S size 140mm / M size 160mm, L size 170mm
-
Seat
Syncros Savona 2.0 V-Concept, CrMo rails
-
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, -0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
-
Front hub
Formula CL-811 / 15x110mm
-
Rear hub
Formula CL-148M / 12x148mm
-
Spokes
Stainless Black 15G / 1.8mm
-
Rims
Syncros X-30S / 32H / 30mm / Sleeve Joint, Tubeless ready
-
Front tire
Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
-
Rear tire
Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
-
Extras
Syncros Fork Fender
-
Approx weight in KG
14.8 (Tubeless setup)
-
Approx weight in LBS
32.63 (Tubeless setup)
-
Max. system weight
128kg (The overall weight includes the bike, the rider, the equipment, and possible additional luggage.)
-
Head tube angle (S, M, L)
65.1 °, 65.1 °, 65.1 °
-
Head tube length (S, M, L)
90.0 mm (3.5 in), 100.0 mm (3.9 in), 120.0 mm (4.7 in)
-
Top tube horizontal (S, M, L)
570.1 mm (22.4 in), 602.2 mm (23.7 in), 631.3 mm (24.9 in)
-
Standover height (S, M, L)
728.5 mm (28.7 in), 738.5 mm (29.1 in), 753.5 mm (29.7 in)
-
BB offset (S, M, L)
-33.0 mm (-1.3 in), -33.0 mm (-1.3 in), -33.0 mm (-1.3 in)
-
BB height (S, M, L)
342.5 mm (13.5 in), 342.5 mm (13.5 in), 342.5 mm (13.5 in)
-
Wheel base (S, M, L)
1,182.0 mm (46.5 in), 1,216.0 mm (47.9 in), 1,249.0 mm (49.2 in)
-
BB center to top of seattube (S, M, L)
380.0 mm (15.0 in), 410.0 mm (16.1 in), 440.0 mm (17.3 in)
-
Seat angle (S, M, L)
76.8 °, 77.1 °, 77.2 °
-
Chainstay (S, M, L)
440.0 mm (17.3 in), 440.0 mm (17.3 in), 440.0 mm (17.3 in)
-
Reach (S, M, L)
430.0 mm (16.9 in), 460.0 mm (18.1 in), 485.0 mm (19.1 in)
-
Stack (S, M, L)
617.0 mm (24.3 in), 626.1 mm (24.6 in), 644.2 mm (25.4 in)
-
Stem length (S, M, L)
40.0 mm (1.6 in), 40.0 mm (1.6 in), 50.0 mm (2.0 in)
-
Trail (S, M, L)
125.8 mm (5.0 in), 125.8 mm (5.0 in), 125.8 mm (5.0 in)
-
Fork length (S, M, L)
571.0 mm (22.5 in), 571.0 mm (22.5 in), 571.0 mm (22.5 in)
-
Maximum Seatpost Insertion (S, M, L)
173.0 mm (6.8 in), 204.0 mm (8.0 in), 234.0 mm (9.2 in)
-
Crank Length (S, M, L)
170.0 mm (6.7 in), 170.0 mm (6.7 in), 175.0 mm (6.9 in)
