FRAME
Genius Carbon HMF Mainframe with Alloy 6061 Swingarm, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
FORK
FOX 36 Float Performance Elite Air FIT4, 3-Modes with low Speed adj. / Kabolt 15x110mm axle, 44mm offset / tapered steerer / Reb. Adj. / Lockout, 160mm travel
REAR SHOCK
FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 150-100-Lockout / T185X55mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes
REAR DERAILLEUR
SRAM GX Eagle AXS 12 Speed, Wireless Electronic Shift System
SHIFTERS
SRAM GX Eagle AXS Rocker Controller
CRANKSET
SRAM GX Eagle DUB, 55mm CL / 32T
CHAINGUIDE
SCOTT custom
BB-SET
SRAM DUB PF 92 MTB Wide / shell 41x92mm
CHAIN
SRAM CN GX Eagle
CASSETTE
SRAM XG1275 / 10-52 T
BRAKES
Shimano XT M8120 4 Piston Disc
ROTOR
Shimano SM-RT76 / 6 Bolt / 203/F and 180/R
HANDLEBAR
Syncros Hixon iC Carbon, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8° / 780mm, Syncros Endurance lock-on grips
SEATPOST
Syncros Duncan Dropper Post 1.5, 31.6mm / S size 140mm / M size 160mm / L size 170mm / XL size 200mm
SEAT
Syncros Tofino 1.5 Regular, Titanium rails
HEADSET
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
WHEELSET
Syncros Revelstoke 1.5 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
FRONT TIRE
Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
REAR TIRE
Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
EXTRAS
SRAM AXS Powerpack, Syncros Fork Fender
APPROX WEIGHTS IN KG
14.1 (Tubeless setup)
APPROX WEIGHTS IN LBS
31.09 (Tubeless setup)
MAX. SYSTEM WEIGHT
128kg
