Frame
JR16 V-Brake, Alloy 6061, Bended TT, Semi int. HT, Rigid Fork
Fork
Rigid Fork, Alloy 6061, 16", V-Brake Pivot
Crankset
Prowheel, 26T
Bottom bracket
Feimin, BB68, cartridge, square taper
Chain
KMC S1
Cassette
Freewheel Sprocket 16T
Brake levers
Tektro Kids’ Lever, adjustable reach
Brakes
Tektro J-310 V-Brake
Grips
Syncros Kids' Grips Toddler, ID19, extra impact protection
Handlebar
Leadtec Kids' riser bar alloy D:19, 20mm rise, 25.4mm clamp
Stem
Ahead, Alloy, 25.4mm clamp
Seat
Syncros KIDS II incl. seatpost 26.8mm
Headset
ZS44-50mm, 1 1/8"
Front hub
Alloy, sealed bearing, screw type allen key, 16H
Rear hub
Alloy, sealed bearing, screw type allen key, 16H
Front rim
Alloy, 16H, 305-21, A/V, for V-Brake
Rear rim
Alloy, 16H, 305-21, A/V, for V-Brake
Front tyre
Kenda Booster 16 x 2.0, 30TPI
Rear tyre
Kenda Booster 16 x 2.0, 30TPI
Pedals
Kids' pedals w/Reflector
Extras
Kickstand
Accessories
Syncros Stem Protector, Chainguard closed type
Weight
6.1 kg (w/o pedals and kickstand)
Max system weight
50 kg
Body height
95–115 cm (37–45")
Head tube angle
70.0°
Head tube length
90.0 mm (3.5 in)
Top tube horizontal
395.0 mm (15.6 in)
Standover height
452.0 mm (17.8 in)
BB height
105.0 mm (4.1 in)
Wheel base
718.0 mm (28.3 in)
BB center to top tube center
155.0 mm (6.1 in)
BB center to top of seat tube
210.0 mm (8.3 in)
Seat angle
70.0°
Chainstay
290.0 mm (11.4 in)
Reach
276.4 mm (10.9 in)
Stack
325.8 mm (12.8 in)
